KUS temperature sensor for engine or gear oil

Description

KUS oil temperature sensor (max. 150°C) for engine or gear oil indicators

This sensor main body is made from brass. It has a IP67 protection rank.

It is a type 3 sensor which is one of the most common versions. It sends an Alarm Signal at 120°C.

Technical data
Rated power for alarm switch: 1.2 ~ 3 Watt
Temperature alarm tolerance: +/- 3 °C
Type of alarm touch:  The switch turns off when the temperature rises
Temperature response time: Minimum 3 minutes after power supply electrified
L1 = 41 mm
L2 = 71,5 mm

Available versions

Thread: M14x1,5 (alarm temperature 120°C)
Thread: M16x1,5 (alarm temperature 120°C)
Thread: 3/8″-18NPT (alarm temperature 120°C)
