Description
KUS level sensor S3 for fuel and water tanks
The sensor has a 1 1/4″ BSP thread, which allows to screw the sensor directly into the tank. The body is made of AISI 316 stainless steel. Waterproof according to IP67
Supplied complete with seal. Can be used with 12 and 24 volt systems. The connection cable length is 46 cm.
Technical Data
Output signal: 0-190 Ohm (0 empty / 190 full)
Rated power: 125mW
Rated current for alarm switch: 500 mA
Operation temperature: -40°C bis +85°C
Resolution range: 21 mm
This level sensor is available in lengths of 20 – 70 cm. (Lenghts up to 160 cm on request)
